Sinexcel ISUNA Series

Single phase hybrid inverter

3-10kW

2 MPPT

Single phase hybrid inverter is suitable for residential rooftop appliation to transform solar energy into power, compatible with most of storage batteries, enpower your home anytime.

Features

Max. 15 units

High scalability

98%

Max. efficiency

Ultra silence

Natural cooling

Smart load control

Leakage current protection

150%

PV configuration

110%

output overload

80-550V

Wider MPPT voltage range

APP+H5

data visible smart data analysis

Datasheet

Model Name

Isuna 3000S

Isuna 4000S

Isuna 5000S

Isuna 6000S

Off-grid Output
Nominal Output Power	3000W	4000W	5000W	6000W
Nominal Voltage	220V/230V/240V
Nominal Frequency	50/60Hz
Nominal Output Current	13.6A	18.2A	22.7A	27.2A
Nominal Output THDu	<2%

On-grid Parameter
Nominal Output Power	3500W	5000W	6000W	6000W
Max. Input Current	20A	26.67A	27.5A	27.5A
Nominal Grid Voltage	220V
Output Current from Grid	13.6A	22.7A	27.2A	27.2A
Input Voltage Range	184-264V
Nominal Frequency	45-65Hz

PV Input
Max. Input Power	4500Wp	6000Wp	8000Wp	9000Wp
Starting Voltage	75V
Max. Input Voltage	600V
MPPT Operating Voltage Range	80-550V
Full Load MPPT Operating Voltage Range	300-500V
Nominal Input Voltage	2
Nominal Input Voltage	360V
Max. Input Current	13A/13A

Battery Parameter
Battery Type	Lithium-ion
Nominal Battery Voltage	48V
Battery Voltage Range	42-60V
Max. Charging Voltage	≤60V
Max. Continuous Discharging Current	75A	85A	100A	100A
Max. Continuous Discharging Power	3750W	4250W	5000W	5000W
Communication Port	RS485/CAN

Efficiency
Max. Efficiency	97.5%	97.8%	98.0%	98.0%
European Efficiency	97.2%	97.3%	97.5%	97.5%
Max. Battery Charging Efficiency	94.6%
Max. Battery Discharging Efficiency	94.6%

General Data
Weight	20kg
Size((LWH)	515mm490mm184mm
Noise	<25dB(A)
Operating Temperature Range	-25℃~+60℃
Cooling Method	Natural cooling
Ingress Protection Grade	IP65
Communication Port	H5/LED/App
Communication Port	RS485/CAN
Protection	PV Insulation Resistance Detection, Residual Current Monitoring, Anti-islanding Protection, PV ReversePolarityProtection, AC Overcurrent Protection, AC Short Circuit Protection, AC Overvoltage Protection, Surge Protection.

Certification
CE_LVD	IEC 62109-1:2010, IEC 62109-2:2011, EN 62109-1:2010, EN 62109-2:2011
CE_EMC	EN61000-6-1, EN61000-6-2, EN61000-6-3, EN61000-6-4
Grid	VDE-AR-N 4105, VDE V 0126-1-1, G98/G99, CEI 0-21, EN50549, RD 1699, NRS 097-2-1, AS 4777.2, R25
